| Type | K0,5S+KSY45 |
 |
 |
| Order no. | 56126+56064 | ||
| Crystal size | 34 mm Ø | ||
| Frequency | 0,5 MHz | ||
| Beam angle | 45 ° | ||
| Bandwidth | 0,35 .. 0,65 MHz | ||
| Operating range | 50 .. 200 mm | ||
| Near field length | 21 mm | ||
| Echo width | 8 mm | ||
| Contact area | 60x50 mm | ||
| Remark | These probes are identical to the straight beam probes having the same name. This is the reason that wedges KSY.. must be ordered separately for longitudinal waves and KS.. for transverse waves, see accessories! |
